E14 Solder Lamp Holder
£0.49 Ex. VAT
E14 LED Lamps / Bulbs
Price range: £1.75 through £2.35 Ex. VAT
E10 Solder Lamp Holder
£0.49 Ex. VAT
Strip back the wire to the copper and solder the wire to the lamp holder conductors.
Description
Thread length: 20mm
Size of hole required to fit: 16mm
Maximum wattage lamp to be used: 10w
Suitable for voltages upto 60v
Maximum thickness of material for installation is 10mm
If yours is thicker, you will need to rebate a 40mm area on the back of the material, leaving a max thickness of 10mm
Additional information
| Dimensions | 20 cm |
|---|
Related products
E10 Cabochon Caps (UFO)
UFO E10 Cabochon Caps
Colour = Clear (If you are looking for any other colour please get in touch)
40mm H x 40mm D tapering down to 30mm at the base
Supplied in 2 parts - Cap & Base
Our E10 Cabochons create a strikingly radial effect from the base, while the cap generates highly attractive effects, emitting powerful luminosity from all angles, for all to see.
E10 Spike Lamp Holder
With our spike on holder there is no need to strip the wire back to expose the copper. All you have to do is place the wires in the two openings on the back of the lamp holder (on top of the spikes) and screw the compression nut on to make a connection.
Supplied in 2 parts – Lamp Holder & Compression Nut
E10 LED Lamps / Bulbs
Our Italian made LED lamps, use the highest quality parts and manufacturing process, to guarantee the best light output and long lifespan.
They have been designed specifically to fit into our E10 Cabochon Caps.
Fitting: E10 (MES)
Wattage: 24v & 60v: 1.2w
Voltages Available: 24v, 60v AC / DC
Colours Available: Warm White (2,700k-3000k) & Cool White (10,000k)
Dimmable: Yes
E14 LED Lamps / Bulbs
Our Italian made LED lamps, use the highest quality parts and manufacturing process, to guarantee the best light output and long lifespan.
They have been designed specifically to fit into our E14 Cabochon Caps.
Fitting: E14 (SES)
Wattage: 1.5w
Voltages Available: 24v, 60v & 240v
Colours Available: Warm White (2,700k-3000k) & Cool White (10,000k)
Dimmable: Yes - 24v & 60v ONLY
Economical Range – E14 LED Lamp / Bulb – 24v – Cool White
END OF THE LINE STOCK - Our Economical Range of LED lamps / bulbs are a like for like match of cool white colour output, to ones supplied by others in the UK. Please email us if you need more information: rue@amusementlighting.co.uk
They have been designed specifically to fit into E14 Cabochon Caps.
Fitting: E14 (SES)
Wattage: 1w
Voltages Available: 24v
Colours Available: Cool White (8,000k)
Dimmable: No
Warranty: 1 Year
